Z-Type Folding Container House

China Foldable Flat Pack Container Homes For Sale

In China, We have developed a new type of collapsed container house, which can be easily transported by installing the wall panel of the packing box in advance.

  • Customizable:

    Available
  • MOQ:

    7 Units
  • Shipping Port:

    Shanghai
  • Place of Origin:

    China
  • Product Detail

China Collapsed Container House Van House Container Homes For Sale In Png

Foldable convenience meets modern living in our Flat Pack Container House.

Foldable convenience meets modern living in our Flat Pack Container Home.



Portable and easy to assemble, it’s the perfect solution for temporary housing.

Portable and easy to assemble, it’s the perfect solution for temporary or permanent housing.

Create a cozy and functional living space with our customizable interior design options.

Create a cozy and functional living container with our customizable interior design options.



Foldable Flat Pack Container is standard designed, industrialized produced and with long life span. It can be installed conveniently, easily transportable and reused.

Because of the foldable characteristics, it can be installed in 5 minutes.



Product Specifications Folded Height  H=440mm 40HQ can load 10 sets
L*W*H(mm)  5830mm*2500mm*2470mm
 Inner size: 5650mm*2320mm*2200mm
Roof Form  Flat Roof
Number Of Layers  ≤2 layers
Structure Column  Specification 50mm*160mm
 Roller Beam
 Material Thickness 2.3mm
 Material Q235B
Roof Main Beam  Specification 50*160mm
 Roller Beam
 Material Thickness 2.3mm
 Material=Q235B
Roof Secondary Beam  Galvanized Cold Rolled Section Steel C Type
 Material Thickness=1.0mm
 6 Pices
 Material Q235B
Ground Main Beam  Height 50*140mm
 Roller Beam
 Material Thickness 2.3mm
 Material=Q235B
Ground Secondary Beam  Galvanized Cold Rolled Section Steel C Type
 Material Thickness 1.5mm
 9 Pices
 Material=Q235B
Bolt  8.8 Class High-Strength Bolts, 6
Paint  Electrostatic spraying plastic powder baking varnish   ≥80μm
Roof Roof Panel  EPS Color Steel Sandwich Panel
 Thickness=50mm
 Color White-Gray
 Free fall
Ground Substrate  18mm Fireproof Glass Magnesium Board
Wall Insulation Cotton  50mm Thickness Color Steel EPS Sandwich Panel
 Class B Fireproof
Color steel Plate  Panel Coler Streel Plate Thickness 0.4mm
Door Specification  Width×Height=840mm*1900mm
Material  Steel Door
 Concealed Lock
Window Specification  950mm*1100mm
Fram Material  Plastic Steel
Glass  Single Layer Glass



Folding Flat Pack Container



Shanghai HIG HOUSE Co., Limited. which covers 350,000 square meters and has an annual output of 200,000 containers, focusing on designing and developing, producing, selling, installing, operating, and serving as a whole, providing one-stop box rental and manufacturing for customers.

HIG HOUSE covers a series of products such as steel structure workshops, flat pack container house, modified shipping container house, detachable container house, folding container house, expandable container house, portable ion, installation, Services, and other one-stop solutions.


     After 15 years of hard work by the company’s core team, it has obtained 46 invention patents and utility model patents.

     We take the need of customers as the base, green safe, economical, and comfortable living experience as the root and development of the industry as the purpose.
